Program Overview

The Steward Program's main functions include:

1. Validator Selection and Management: The program selects validators, monitors their performance, and adjusts stake allocations to maintain optimal performance.
2. State Machine: A state machine representing the progress throughout a cycle (10-epoch period) for scoring and delegations.
3. Adding and Removing Validators: Automatically handles the addition and removal of validators based on predefined criteria.
4. Admin Abilities: Allows administrators to update parameters, manage a blacklist, pause/unpause the state machine, and execute passthrough instructions for SPL Stake Pool.

State Machine

The state machine represents the progress throughout a cycle (10-epoch period for scoring and delegations).

Compute Scores

At the start of a 10 epoch cycle (“the cycle”), all validators are scored. We save the overall score, which combines yield performance as well as binary criteria for eligibility, and we also save the yield-only score.

The score is for determining eligibility to be staked in the pool, the yield_score determines the unstaking order (who gets unstaked first, lowest to highest).

The following metrics are used to calculate the score and yield_score:

• mev_commission_score: If max mev commission in mev_commission_range epochs is less than threshold, score is 1.0, else 0
• commission_score: If any commission within the individual's validator history exceeds the historical_commission_threshold, score it 0.0, else 1.0. This effectively bans validators who have performed commission manipulation.
• blacklisted_score: If validator is blacklisted, score is 0.0, else 1.0
• superminority_score: If validator is not in the superminority, score is 1.0, else 0.0
• delinquency_score: If delinquency is not > threshold in any epoch, score is 1.0, else 0.0
• running_jito_score: If validator has a mev commission in the last 10 epochs, score is 1.0, else 0.0

Note: All data comes from the ValidatorHistory account for each validator.

To formula to calculate the score and yield_score:

let yield_score = (average_vote_credits / average_blocks)
    * (1. - commission);

let score = mev_commission_score
    * commission_score
    * blacklisted_score
    * superminority_score
    * delinquency_score
    * running_jito_score
    * yield_score

As a validator, in order to receive a high score for JitoSOL, you must meet these binary eligibility criteria, and return a high rate of rewards to your stakers. The eligibility criteria ensure that we're delegating to validators that meet some important properties for decentralization, Solana network health, operator quality, and MEV sharing. The yield score is an objective way to compare validators' relative yield and ensure we're returning a competitive APY to JitoSOL holders, which in turn attracts more stake to delegate to validators.

In this version 0 of the score formula, there is no weighting of any factor above any other, because it is a product of all factors. But because all factors besides yield_score will only be 1.0 or 0.0, yield is the main factor for determining validator ranking assuming all eligibility criteria is met. Even if one of the eligibility factors is not met, or the score is not high enough to be selected for the pool delegation, it is still advantageous to have a high yield_score as it is used for ranking which validators to unstake first.

For a breakdown of the formulas used for each score, see the Appendix.

Take a look at the implementation in score.rs

Compute Delegations

Once all the validators are scored, we need to calculate the stake distribution we will be aiming for during this cycle.

The top 200 of these validators by overall score will become our validator set, with each receiving 1/200th of the share of the pool. If there are fewer than 200 validators eligible (having a non-zero score), the “ideal” validators are all of the eligible validators.

At the end of this step, we have a list of target delegations, representing proportions of the share of the pool, not fixed lamport amounts.

Idle

Once the delegation amounts are set, the Steward waits until we’ve reached the 95% point of the epoch to run the next step.

Compute Instant Unstake

All validators are checked for a set of Instant Unstaking criteria, like commission rugs, delinquency, etc. If they hit the criteria, they are marked for the rest of the cycle.

The following criteria are used to determine if a validator should be instantly unstaked:

• delinquency_check: Checks if validator has missed > instant_unstake_delinquency_threshold_ratio of votes this epoch
• commission_check: Checks if validator has increased commission > commission_threshold
• mev_commission_check: Checks if validator has increased MEV commission > mev_commission_bps_threshold
• is_blacklisted: Checks if validator was added to blacklist blacklisted

If any of these criteria are true, we mark the validator for instant unstaking:

let instant_unstake =
    delinquency_check || commission_check || mev_commission_check || is_blacklisted;

Take a look at the implementation in score.rs

Rebalance

One instruction is called for each validator, to increase or decrease stake if a validator is not at the target delegation.

For each validator, we first check if the target balance is greater or less than the current balance.

If the target is less, we attempt to undelegate stake:

When undelegating stake, we want to protect against massive unstaking events due to bugs or network anomalies, to preserve yield. There are two considerations with this: There are 3 main reasons we may want to unstake. We want to identify when each of these cases happen, and let some amount of unstaking happen for each case throughout a cycle.

• the pool is out of line with the ideal top 200 validators and should be rebalanced,
• a validator is marked for instant unstake, or
• a validator gets a stake deposit putting it far above the target delegation.

We want to run the rebalance step in parallel across all validators, meaning these instructions can be run in any order, but we need to have some notion of the unstaking priority/ordering so the worst validators can be unstaked before the cap is hit. Pre-calculating the balance changes is difficult since balances can change at any time due to user stake deposits and withdrawals, and the total lamports of the pool can change at any time.

To address 1: we set a cap for each unstake condition, and track the amount unstaked for that condition per cycle. (scoring_unstake_cap, instant_unstake_cap, stake_deposit_unstake_cap)

To address 2: in each instruction, we calculate how much this validator is able to be unstaked in real-time, based on the current balances of all validators, unstaking caps, and which validators would be “ahead” in priority for unstaking before caps are hit. (Lower yield_score = higher priority). If all the “worse” validators will be unstaked and hit the caps before this one can, no unstaking is done on this validator.

For each validator, its active stake balance in lamports is then saved. In the next epoch, any lamports above this can be assumed to be a stake deposit, and can be unstaked.

If the target is greater, we attempt to delegate stake:

In a similar vein to unstaking, we want to be able to customize the priority of staking so that instructions can be run in any order, but stake is going to better validators given a limited pool reserve.

We calculate how much this validator is able to be staked in real time, given the number of validators “ahead” in priority (based on overall score). If all validators who need stake are able to be filled and there is still stake left over in the reserve, this validator gets the stake it needs, either up to the target or until the reserve is empty, whichever is first.

If stake was delegated, the balance is updated.

Note that because of the 1-epoch delay in cooling down stake that’s unstaked from validators, there will be many instances where the reserve won’t have enough balance to match the stake needs for everyone, but the following epoch, it will (assuming no withdrawals).

If we are already at the target, nothing happens.

Progress is marked so this validator won’t be adjusted again this epoch. After all validators’ progress is marked “true”, we transition to idle.

Rest of the cycle

After unstaking is done, the state machine moves back into Idle. In next epoch and in the rest of the epochs for the cycle, it repeats these steps:

• Compute Instant Unstake
• Rebalance
• Idle

At the start of the next cycle, we move back to Compute Scores, and all those pieces of state are reset to 0.

Diagram

View in Figma

Validator Management

Adding Validators

The JitoSOL pool aims to have as many active validators as possible in the pool, meaning they are able to get scored and considered for delegation. This does NOT mean they are guaranteed stake (see the State Machine section above for how validators receive stake). Validators are added permissionlessly if they meet the following criteria:

• At least 5 epochs of voting.
• Minimum SOL stake of 5000.

There are approximately 1300 validators that meet these criteria today, with a capacity for 5000 validators.

Removing Validators

Validators are removed if:

• The validator’s vote account closes.
• The validator stops voting for 5 epochs, leading to the deactivation of the stake account in the stake pool.

Admin Abilities

There are 3 authorities. blacklist_authority, parameters_authority, and admin.

blacklist_authority is used to add/remove validators to/from the blacklist to prevent delegation.

parameters_authority is used to update the parameters, which affects scoring and delegation.

admin is used for all other perimissioned actions, including updating authorities, pausing the state machine, and executing passthrough instructions for SPL Stake Pool that require the staker as a signer.
